The LEUCO 161619 HW Grooving Saw Blade is a tungsten carbide tipped circular saw blade designed for clean, accurate grooving in solid timber and wood-based panels. With a 150mm cutting circle diameter, 7.0mm cutting width, 5mm hub width, 30mm bore and Z12 tooth count, it is suited to workshop and production environments where controlled groove width and consistent finish are important.
LEUCO lists this blade for use on moulders and double end tenoners, making it suitable for joinery, cabinetmaking, furniture manufacturing and panel processing applications. LEUCO also notes that, with Z12 and Z18 grooving saw blades, other groove widths may be possible by combining tool sets, subject to correct calculation of cutting widths, carbide projection and spacer thickness.
The blade has a maximum speed rating of 12,700 RPM, which must be checked against the machine and setup before use. For help confirming suitability, bore requirements or sharpening support, contact AST on 1300 117 012 or email [email protected].
Key Features
- LEUCO HW tungsten carbide grooving saw blade
- 150mm cutting circle diameter
- 7.0mm cutting width
- 5mm hub width
- 30mm bore diameter
- Z12 tooth count
- Maximum RPM: 12,700 min⁻¹
- Designed for chip-free grooving in solid woods and wood-based panels
- Suitable for moulders and double end tenoners
Suitable Applications
- Chip-free grooving in solid timber
- Grooving wood-based panels
- Cabinetmaking and joinery production
- Furniture manufacturing
- Moulder applications
- Double end tenoner applications
- Compatible tool-set grooving applications, where correctly configured
